Smart Glass also known as PDLC Glass provides Instant and precise privacy control
Efficient use of space in the built environment
Smart Glass blocks 98+% of damaging UV rays
Eco friendly product
Exceptional optical qualities that reduce glare and eye strain
Large sizes of many shapes can be produced
Our Smart Glass provides stable colour characteristics for the life of the unit
Hygienic low maintenance reducing the transmission of MRSA and VRE pathogens
Smart Glass enhances corporate image
Reduces uncomfortable “Gold fish bowl” feeling when living or working in high-density buildings such as apartment blocks or office complexes
Reduced fading of carpets, furniture and protect valuable artwork with the advantages of Smart Glass
High UV stability
Low working voltage
High video contrast at any viewing angle and any illumination level
Long life – tested to in excess of 3,000,000 cycles gives our Smart Glass an incredible advantage over competition
Smart Glass Maximum Size: Adhesive Film 4.9 feet wide
Smart Glass Maximum Size: Non Adhesive 5.90 feet wide x 98 feet long
Film Thickness: 0.4mm Standard Smart Glass Thickness 10mm and 12mm
Smart Glass Film composite PDLC
In Smart Glass polymer dispersed liquid crystal devices (PDLCs), liquid crystals are dissolved or dispersed into a liquid polymer followed by solidification or curing of the polymer. During the change of the polymer from a liquid to solid, the liquid crystals become incompatible with the solid polymer and form droplets throughout the solid polymer. The curing conditions affect the size of the droplets that in turn affect the final operating properties of the "smart window". Typically, the liquid mix of polymer and liquid crystals is placed between two layers of plastic that include a thin layer of a transparent, conductive material followed by curing of the polymer, thereby forming the basic sandwich structure of the smart window. This structure is in effect a capacitor.
Contacts from a UL Certified low voltage power supply are attached to the transparent electrodes. With no applied voltage, the liquid crystals are randomly arranged in the droplets, resulting in scattering of light as it passes through the smart glass window assembly. This results in the translucent, "milky white" appearance. When a voltage is applied to the electrodes, the electric field formed between the two transparent electrodes on the glass causes the liquid crystals to align, allowing light to pass through the droplets with very little scattering and resulting in a transparent state. The degree of transparency can be controlled by the applied voltage. This is possible because at lower voltages, only a few of the liquid crystals align completely in the electric field, so only a small portion of the light passes through while most of the light is scattered. As the voltage is increased, fewer liquid crystals remain out of alignment, resulting in less light being scattered. It is also possible to control the amount of light and heat passing through, when tints and special inner layers are used. It is also possible to create fire-rated and anti X-Ray versions for use in special applications. This technology has been used in interior and exterior settings for privacy control (for example conference rooms, intensive-care areas, bathroom/shower doors) and as a temporary projection screen.
Smart glass or switchable glass (also smart windows or switchable windows in these applications) is glass or glazing whose light transmission properties are altered when voltage, light or heat is applied. Generally, the Smart glass changes from translucent to transparent, changing from blocking some (or all) wavelengths of light to letting light pass through.
Our Smart glass technologies include polymer dispersed liquid crystal devices.
When installed in the envelope of buildings, smart glass creates climate adaptive building shells, with the ability to save costs for heating, air-conditioning and lighting and avoid the cost of installing and maintaining motorized light screens or blinds or curtains. Smart Glass obtains 99% UVA and UVB protection as well as a estimated 40% heat rejection.
Critical aspects of smart glass are the low consumption of electricity as well as functional features such as the speed of control, sunlight control, sound control, automation control, App control, possibilities for dimming, and the degree of transparency.
1-Does Smart Glass privacy Glass blocks harmful UV rays?
Yes, It blocks over 98% of the harmful UV rays in both its energized and un-energized state.
2-Is Smart Glass energy efficient?
Yes, Smart Glass has been considered a green product that consumes between 4 and 6 watts per meter squared.
3-Can customers install Smart Glass themselves?
Yes, we offer a complete prewired custom kit. We do recommend a installation performed by a certified contractor.
4-What is the difference between Smart Film Self Adhesive and Smart Film NON-Adhesive backings?
Smart Film Glass offers a Self Adhesive and a Non-Adhesive switchable privacy film that has the ability to contour to the curves of various types of glass. Smart Film is very popular for projection screens, electronic blinds, white boards, and high tech window treatments. Smart Glass switchable privacy Glass provides maximum clarity when energized and extreme privacy when powered off. The only difference between the two switchable films is that Self Adhesive has a peel and stick backing and or non-adhesive can be installed with a double sided adhesive clear 3m VHB tape.
5-Smart Glass Price?
Every Smart Glass project is different and we custom manufacture your material into almost any shape or size, pre-wire, test and send you a ready to install kit with a package price. We have the quickest lead times in the business. We offer a price match guarantee!
6-How can I purchase or get a job quote?
If you would like to get a quote, click the Contact Us Form for a no obligation quote and provide us the details of your project.
7-Can Smart Film be installed on the half of the glass only?
Yes, you can install our Smart Film privacy film on the top half or bottom half only if desired.
8-Do you offer custom cut?
Yes, our Smart Glass is all custom cut to order. Call for a Free no obligation quote.
9-Can you project on Smart Glass?
Yes, Smart Glass is ideal with its extremely high gain rate to be used as a projection film. We have many happy retail customers that utilize their store glass façade as a video billboard.
Operating voltage: 42-52VAC
Frequency: 60 HZ
Ampere: 100mA/ sqm
Power consumption: 4-6W/sqm
Parallel light transmittance: 80% on 10% off
Sunlight transmittance: 80% on 10% off
Haze: 2% on 80% off
Max size: 1800 * 30000 mm
Thickness Standard 10-12mm
Viewing angle: 150 degree
Switch: 3 million times switch on and off
Estimated Life span: 10 years
Heat Rejection 40% Off
UV Protection 99% On/Off
